Reference: I-139 Power supply : 230V. AC/1W Maximum load : 5 A Dimensions : 84x55x33 mm. Weight : 166 grs. Operating time : 2 a 45 min. |
Timers with relay output, activation by contact closure and timing when releasing the input contacts.
The circuit will remain idle until the contacts of the activation input are pressed or closed, at this moment the output relay will be connected.
When said activation input is released or opened, the circuit will start timing, without disconnecting the relay.
When the timer expires the relay will release and the module will return to the idle state.
Recommended box C-7523
